PV Smart Junction Box 16 Input Lighting Surge Protection Solar Combiner Box

Basic Info.

Model NO.	SD600
Transport Package	Cartons
Trademark	IFIND
Origin	Jiaxing
HS Code	8537109090
Production Capacity	200000

Product Description

PV Smart Junction Box 16 Input Lighting Surge Protection Solar Combiner Box
In order to reduce the connection line between photovoltaic(solar) modules and inverter, easy maintenance, improve reliability, increase the DC convergence equipment between photovoltaic(solar) modules and inverter;The advanced digital technology is used to monitor the electrical parameters of the bus box and to realize data communication through cable.

Functional features of PV Smart Junction Box 16 Input Lighting Surge Protection Solar Combiner Box
1.Integrated photovoltaic special lightning protection device, full range of lightning protection, anti-connection reverse function, 16 channels monitoring system
2. Equipped with special photovoltaic fuse overcurrent protection device, the system is more secure
3 IP65 high protection level, suitable for complex outdoor environment
4.With 8/16 series of products, flexible scheme configuration
5 Internal power, no need for external auxiliary power supply;To meet the application requirements in areas without electricity

Specification

Electric parameter
System maximum dc voltage	1000/1200v
Maximum input current for each string	15A
Maximum inputs strings	16
Maximum outpot swithc current	180A
Number of inverter MPPT	1
Number of output strings	1
	Lightning protection
Category of test	2 grade protection
Nominal discharge current	20kA
Maximum discharge current	40kA
Voltage pretection level	3.8kV
Maximum continuous perating voltage Uc	1050V
Poles	3P
Structure characteristic	Plug-push module
	System
Protection grade	IP65
Output switch	DC isolator switch(standard)/DC circuit breaker(optional)
MC4R waterproof connectors	Standard
PV DC fuse	Standard
PV surge protector	Standard
Monitoring module	Optional
Prevening diode	Optional
Box material	PVC
Installation method	Wall mountion type
Operating temperature	-25ºC-+55ºC
Elevation of temperature	2000m
Permissible relative humidity	0-95%, no condensation
	Mechanical parameter
Width*High*Depth	800mm*600mm*200m

Drawing of PV Smart junction Box 16 Input Lighting Surge Protection use for solar combiner boxApplication of PV Smart Junction Box 16 Input Lighting Surge Protection Solar Combiner BoxAbout the process of IFIND's product
